Vertical Autoclave Double Chamber Water Level

Vertical Autoclave Double Chamber Water Level

Get a Price/Quote

Product Details:

Function Sterilization through Pressurized Steam
Measurement Range Temperature: up to 134C, Pressure: up to 2.2 kg/cm
Accuracy 1C Temperature, 0.5 psi Pressure
Features Double Chamber, Automatic Water Level Cut-off, Pressure Gauge, Safety Valve, Exhaust Valve, User-Friendly Controls
Frequency 50/60 Hz
Instruments Type Autoclave
Storage Instructions Keep in a clean and dry area, away from corrosive chemicals
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

X

Vertical Autoclave Double Chamber Water Level Price And Quantity

Vertical Autoclave Double Chamber Water Level Product Specifications

Dimension (L*W*H) Varies by Model (typically 400 x 600 x 1200 mm)
Frequency 50/60 Hz
Use Sterilization of laboratory instruments, media and other materials
Weight Approx. 90-130 kg (Depending on Capacity)
Voltage 220V / 230V AC
Real-Time Operation Yes
Storage Instructions Keep in a clean and dry area, away from corrosive chemicals
Display Type Analog / Basic Digital (Pressure & Temperature indication)
Noise Level Low
Equipment Type Vertical Autoclave Double Chamber Water Level
Usage Type Hospital, Laboratory, Research Facility, Industrial
Instruments Type Autoclave
Technology Steam Sterilization, Automatic Water Level Control
Power Source Electric
Measurement Range Temperature: up to 134C, Pressure: up to 2.2 kg/cm
Color Silver
Operating Type Automatic
Function Sterilization through Pressurized Steam
Material Stainless Steel (Inner and Outer Chamber)
Power Consumption 2-5 kW (Depending on Size)
Condition New
Accuracy 1C Temperature, 0.5 psi Pressure
Wall Mounted No
Features Double Chamber, Automatic Water Level Cut-off, Pressure Gauge, Safety Valve, Exhaust Valve, User-Friendly Controls
Portable No (Mounted on Heavy Duty Castor Wheels)

Product Description

Vertical Autoclave Double Chamber Without Water Level

Double drum single stainless steel chamber with heavy aluminium lid, double safety valves to ensure the safety of the user and the pressure gauge on the top of the lid, rubber gasket placed well between the lid and the unit, release valve of the steam while the cycle complete, Water outlet valve and Two metal handle to hold the unit while movement.

This Autoclave is specially designed for meeting the requirement of General Surgery, Gynecology and Orthopedic surgeries.

Details

Size: 12" x 20"

Heating Coil: 2KW

MOS: Stainless Steel

Specification

MODEL	15	24	35	41
Size - Internal	12 Dia x 20 Depth	16 Dia x 24 Depth	20 Dia x 28 Depth	22 Dia x 30 Depth
Construction of Chamber	S.S. 304	S.S. 304	S.S. 304	S.S. 304
Capacity	35 Liters	75 Liters	150 Liters	175 Liters
Power Consumption	3000 Walts	4000 Walts	6000 Walts	9000 Walts
Operating Pressure	1.2 Kg	1.2 Kg	1.2 Kg	1.2 Kg
Operating Temperature	121°C	121°C	121°C	121°C
Voltage	230 Volt	230 Volt	440 Volt	440 Volt
Control	Digital	Digital	Digital	Digital

Reliable and Safe Sterilization

Engineered with advanced safety mechanisms like automatic cut-off, safety valves, and water level cut-off, the Vertical Autoclave Double Chamber Water Level ensures secure operation every cycle. Its high-quality heater and pressure control system prevent overheating and over-pressurization, guaranteeing both effective sterilization and equipment longevity.

User-Friendly and Efficient Operations

Featuring easy-to-read analog or digital displays for temperature and pressure, along with intuitive controls and integrated water level indicators, this autoclave offers seamless day-to-day operation. The automatic water level control and heavy-duty castor wheels make setup and maintenance straightforward for labs, hospitals, or industrial facilities.

Versatile Applications for Multiple Settings

With chamber capacities from 35 to 150 liters and robust construction, the autoclave is adaptable for sterilizing various laboratory instruments, glassware, culture media, and medical devices. Its adjustable temperature range and fast sterilizing cycles cater to diverse protocols, making it suitable for research facilities, hospitals, and industrial labs.

FAQs of Vertical Autoclave Double Chamber Water Level:

Q: How does the automatic water level control system function in this autoclave?

A: The integrated automatic water level control continuously monitors the water inside the chambers. If the water level drops below a safe threshold, the system automatically triggers a cut-off to prevent heater damage and ensure safe operation.

Q: What are the benefits of the double chamber design?

A: The double chamber design improves thermal efficiency and promotes uniform steam distribution, enhancing the sterilization process. This structure provides effective heat transfer, reducing cycle times and ensuring thorough sterilization for all items within the chamber.

Q: When should I adjust the sterilizing cycle time and temperature?

A: Cycle time and temperature (adjustable between 121C and 134C for 1530 minutes) should be set according to the load type and volume. Heavier or denser materials may require longer cycles and higher temperatures, while lighter loads can be processed more quickly.

Q: Where should the autoclave be installed for optimal performance?

A: Install the autoclave in a clean, dry area, away from corrosive chemicals or direct sunlight. Positioning the unit on its heavy-duty castor wheels allows for manageable mobility and stable placement in laboratories, hospitals, or industrial environments.

Q: What safety features are included to protect users and prevent accidents?

A: The autoclave is equipped with multiple safety features: automatic cut-off, overpressure safety valve, water level cut-off, and a pressure gauge. These ensure the device operates only within safe parameters, reducing the risk of overheating or accidental discharge.

Q: How is the equipment maintained for long-term use?

A: Regularly check the water level indicator, clean the interior chamber with soft non-corrosive materials, and follow storage instructions to keep the autoclave away from corrosive substances. Periodic gasket inspection and proper shutdown after each use will prolong the equipments service life.
