Diagnostic cum therapeutic stimulator , DSL - 007

Diagnostic cum therapeutic stimulator , DSL - 007
Diagnostic cum therapeutic stimulator , DSL - 007
Send Inquiry
Product Code : P 8 A
Product Description

Diagnostic cum therapeutic stimulator , DSL - 007

  • Micro-Controller based
  • Current modes : Galvanic, Int. Galvanic, Faradic, Surge Faradic, Tense (Cont., Burst , PWM , FM), Acupuncture
  • 2 line LCD display
  • Feather touch keys
  • ABS plastic shockproof body
  • Aesthetic look, Compact design Light weight , Easy to use
  • Can be used for Diagnostic as well as therapeutic purpose
  • Treatment timer

Technical Specification:-

  • 2 Pole AM : 5Khz
  • Faradic :40Hz
  • Surge Faradic : On time : 1-10sec, Off Time : 1-10sec
  • Int. Galvanic : Freq. : 1,5,10,50,,100Hz
  • Duration : 0.01, 0.03, 0.1, 0.3, 1, 3, 10, 30, 100, 300ms
  • TNS Frequency : 2,50,80,100,150 Hz (Continuous, Burst, PWM and FM modes)
  • Resolution : 1 div.
  • Weight : Less than 2Kgs
  • Input : 220-240Vac, 50/60Hz
  • Intensity : 0-100 Adj.
  • Dimensions : 275 x 200 x 85mm
  • Carrying case
  • Pair of cable with Electrodes , Straps - 4 Pair
  • Handle with cable with electrode - 1 no
