Automatic Electronic Touniquet

Automatic Electronic Touniquet
Automatic Electronic Touniquet
Send Inquiry
Product Code : P 26 A
Product Description

 :

TRDG 501 - Fetures

* The Cuff Pressure is Maintained to Set Value Automatically During the Operation Period.

* Set Value of Cuff Pressure can be Altered to any other Desired Value Even While it is in Working Mode.

* Sophisticated Alarms to give Better Warning Message.

* This Tourniquet can be Programmed to suit Your Operation and Post-Operation needs by Setting the Parameters Start Delay and Duration.

* Both Start Delay and Duration can be Changed During the Operation.

* Manual Over-Ride for Cuff Deflation During Programmed Timing is also Possible.

Elapsed Time of Operation is Always in Front of you on Display in Min. : Sec. Fashion

* Last Setting Remains in Memory When Power is Turned OFF.

This Tourniquet is Battery OperatedHence Portable and can be used Anytime. Anywhere even for post Operation.

Built in Battery Charging Circuit to Recharge the Battery Immediately by Just Connecting the Power Cord.

Special Cuff Design, Soft Armored Type, so that it will Fast Forever Even it Sharp Objects get in Touch with it.

Elegant, soft Keypad to Dial the Setting or Parameters at ease.

* Cuff Pressure  Setting : 20 to 500 mm of Hg

* The Unit is Compact, Light Weight.

Specifications :

Cuff Pressure - 20 to 500 mm Hg

Start Delay - 0 to 120 Minutes

Duration - 0 to 250 Minutes

Inflation - Motorised Pump

Deflation - EMV Automatic or Manual Override

Pressure Resolution - 2 mm of Hg. (Set Pressure)

Display - 16 x 2 Backlit LCD Display

Operation Method - Micro Controler, Based Controler

Elapsed Time Display - Minutes : Seconds

Power - 6 V DC Battery

Alarms - Pressure Leakage/ Elapsed Time/ 5 min. Before Auto Deflation

Tourniquet Cuff Types - Soft, Armoured Cuff

Cuff Size - Modified LEG 8.5 x 76 cms. Standard ARM 7 x 35 cms. Child 5 x 30 cms.

Weight - 1.5 Kg. Approximate

Dimensions - 165 (w) x 75 (h) x 140 (d) mm.
